Overview

The following diagram illustrates the Duix H5 SDK call flow,
showing how each method and event connects within a real-time digital human session.
This helps developers understand when to initialize, start, interact, and properly close the session.

​
SDK Call Flow

Duix H5 SDK call flow diagram

​
Lifecycle Summary

Below is a simplified description of the SDK’s execution lifecycle:
  1. Initialize
    Call duix.init() with the required configuration (sign, containerLable, conversationId, platform).
  2. Wait for Initialization Event
    Listen for the initialSuccess event to confirm all resources have loaded.
  3. Start the Session
    Invoke duix.start() to begin rendering the digital human and enable audio/video streaming.
  4. Interact in Real Time
    • Use duix.speak() or duix.answer() for text/audio-based responses.
    • Enable or disable speech recognition via duix.openAsr() / duix.closeAsr().
    • Monitor lifecycle events such as speakStart, speakEnd, asrData, and report.
  5. Handle User Actions & Network Events
    • Respond to error or report events for network diagnostics.
    • Use duix.break() to interrupt speech or duix.setVideoMuted() to toggle playback.
  6. Terminate the Session
    • When done, call duix.stop() to gracefully release all WebRTC resources.
    • Optionally bind duix.stop() to window.beforeunload for page refresh or close.

​
Best Practices

  • Always register event listeners before calling duix.start().
  • For browsers with autoplay restrictions, start muted (muted: true) and later unmute via setVideoMuted(false).
  • If using green-screen background removal (wipeGreen: true), ensure the input video uses a pure green background during session creation.
  • To maintain performance, stop the session (duix.stop()) when inactive for long periods.
Tip:
Pair this diagram with the Methods and Events sections
to see both the functional flow and event sequence.
